Stiga 520 DP User Manual

4
EN
ENGLISH
(Translation of the Original Instructions)
1 INTRODUCTION
Read the instruction manual carefully
before starting the machine.
1.1 STRUCTURE OF THE MANUAL
This manual is made up of the cover, the table of
contents, a section containing all the gures and
explanatory text.
Contents are divided into chapters, headings and
subheadings.
This manual contains a number of tables relative
to the dierent engines (if scheduled).
To facilitate reading, highlight the data which
applies to your machine/engine.
Figures
The gures in these instructions for use are num-
bered 1, 2, 3, etc.
Components shown in the gures are marked A,
B, C, etc.
A reference to a gure is written (2).
A reference to component A in gure 2 is written
(2:A).
Headings
The headings in these instructions for use are
numbered in accordance with the following
example:
“2.3 INTENDED USE” is a subheading to “2 GET-
TING TO KNOW THE MACHINE” and is included
under this heading.
When referring to headings, usually only the relati-
ve number is specied, e.g. “See 2.3.1”.
1.2 SYMBOLS
WARNING symbol. Failure to observe
the instructions provided may result in
serious injury and/or material damage.
MANDATORY symbol. Used to indicate
that an operation is mandatory.
PROHIBITION symbol. Used to indicate
that an operation is prohibited.
NOTE symbol. Indicates information or
details which are particularly important.
1.3 TAKING CARE OF THE MANUAL
Keep the manual in good, legible condition, in a
place which is known and easily accessible to the
machine user.
2 GETTING TO KNOW THE MACHINE
The machine described herein is gardening
equipment, a ride-on lawnmower to be precise,
with front cutting.
The machine is tted with an engine which
activates the cutting device, protected by a safety
guard, as well as a drive unit which moves the
machine. The machine is articulated. This means
that the frame is divided into a front section and
a rear section which can be steered in relation to
one another. The articulated steering allows the
machine to turn smoothly round trees and other
obstacles with a very tight turning radius.
The operator can drive the machine and activate
the main commands from a sitting position in the
driver’s seat. The safety devices installed on the
machine stop the engine and the cutting device.
2.1 MODEL [2WD]
This machine is rear wheel drive.
The rear axle is equipped with a hydrostatic
transmission with innitely variable forward and
reverse gear ratios.
The rear axle is also equipped with a dierential to
facilitate turning.
Front mounted accessories are activated by drive
belts.
2.2 MODEL [4WD]
This machine has 4-wheel drive. The power from
the engine to the drive wheels is transferred
hydraulically.
The engine activates an oil pump which, via a
hydraulic circuit, activates the rear and front axles
(wheels).
The front and rear wheels rotate at the same
speed.
Both axles are equipped with a dierential to make
turning easier.
Front mounted accessories are activated by drive
belts.
2.3 INTENDED USE
This machine has been designed and built to mow
grass.
The use of special accessories, envisaged by the
Manufacturer as original equipment or purchasa-
ble separately, allows the user to perform this work
in accordance with dierent operating modes as
illustrated in this manual or the instructions accom-
panying the individual accessories.
