34
ENGLISH
EN
5.5.3 Synchronising, blades
The deck has synchronised blades.
If one of the blades has struck a solid object (e.g. a
stone), the synchronisation may be altered. This
entails a risk of the blades colliding with each oth-
er.
Correctly synchronised blades must be offset 90°
from each other. See fig. 7.
Always check synchronisation after a collision.
If the blades are not synchronised, one or more of
the following faults may have occurred in the cut-
ting deck:
• The positive drive belt has slipped on the gear
wheels.
• Torque limiting between gear wheels and blade
shaft has deployed. The arrows in fig. 8 must be
opposite each other for an intact deck. When
torque limiting has deployed, the arrows are not
opposite each other.
• The blade member is incorrectly installed on
the blade shaft. Can be installed in three differ-
ent positions. See 6:R.
In the event of incorrect synchronisation according
to the two first alternatives, contact an authorised
Stiga workshop for repair.
6 SPARE PARTS
STIGA genuine spare parts and accessories are de-
signed specifically for STIGA machines. Please
note that ‘non-genuine’ spare parts and accessories
have not been checked or approved by STIGA:
The use of such parts and accessories
can affect the function and safety of the
machine. STIGA accepts no responsi-
bility for damage or injuries caused by
such products.
7 DESIGN REGISTRATION
This product or parts thereof is covered by the fol-
lowing design registration:
EG 000503107
GGP reserves the right to make alterations to the
product without prior notification.
