Stiga Park User Manual

63
ENGLISH
EN
5.4.2 Engine Oil
Use oil according to the table below.
Use oil without any additives.
Do not fill with too much oil. This can cause the
engine to overheat.
Change oil when the engine is warm.
The engine oil may be very hot if it is
drained off directly after the engine is
shut off. Therefore allow the engine to
cool a few minutes before draining the
oil.
1. Attach the clamp on the oil drainage hose. Use
a polygrip or similar. See fig. 15-17:Y.
2. Move the clamp up 3-4 cm on the oil drainage
hose and pull out the plug.
3. Collect the oil in a collection vessel.
NOTE! Do not spill any oil on the drive belts.
4. Hand in the oil for disposal in accordance with
local provisions.
5. Install the oil drainage plug and move the clamp
back so that it clamps above the plug.
6. Remove the dipstick and fill with new oil.
Oil quantity:
Comfort: 1,6 l
Prestige: 1,9 l
Royal: 0,9 l
7. After filling up the oil, start the engine and idle
for 30 seconds.
8. Check to see if there is any oil leakage.
9. Stop the engine. Wait for 30 seconds and then
check the oil level in accordance with 4.2.
5.5 Fuel filter
Comfort (Briggs & Stratton)
Replace the fuel filter every season.
Prestige (Kohler), Royal (Honda)
Replace the fuel filter after 1,500 hours of opera-
tion.
Check for fuel leaks once the new filter has been
installed.
5.6 Transmission, oil (Prestige)
The oil in the hydraulic power transmission must
be checked/adjusted and changed at the intervals
given in the table below.
Type of oil: Synthetic oil 5W-50.
Oil quantity when changing: approximately 3.5 li-
tres.
5.6.1 Check – adjustment
1. Place the machine on a flat surface.
2. Read off the oil level in the reservoir. See fig.
18. The level should be level with the line.
3. If necessary, top up with more oil.
5.6.2 Draining
1. Run the machine at variable speeds for 10-20
minutes to heat up the transmission oil.
2. Position the machine completely horizontally.
3. Pull out both disengagement levers according to
fig. 7:A, B.
4. Place one container under the rear axle and one
under the front axle.
5. Open the oil reservoir by removing the cover.
Only a 3/8” square drive may be used
for the oil plug. Other tools will damage
the plug.
6. Remove the oil plug from the rear axle. Clean
the hole and use a 3/8” square drive. See figure
19.
7. Remove 2 drain plugs from the front axle. Use
a 12 mm socket. Allow the oil in the front axle
and pipes to run out. See fig. 20.
8. Check that the gaskets on the drain plugs of the
front axle are intact. See fig. 20. Reinstall the
plugs. Tightening torque: 15-17 Nm.
The oil plug will be damaged if it is
tightened more to than 5 Nm.
9. Check that the gasket on the oil plug of the rear
axle is intact. See fig. 19:V. Reinstall in the rear
axle. Tighten the oil plug to 5 Nm.
10.Draw out the oil from the deeper section of the
reservoir using an oil extractor. See fig. 21.
11.Dispose of the oil according to local regula-
tions.
Machine Oil
Comfort (B&S) Grade Service
class
All temperatures SAE 10W-40 SF
or higher
Below -18° C SAE 5W-30
Above 0° C SAE30
Prestige (Kohler) Grade Service
class
Above 0° C SAE 10W-40 SG
or higher
Below 0° C SAE 5W-20/30
Royal (Honda) Grade Service
class
All temperatures SAE 10W-40 SJ
or higher
Below 0° C SAE 5W-30
Above 10° C SAE30
Action
1st time Then at
intervals
of
Hours of operation
Checking – adjusting level. - 50
Changing the oil. 5 200
