EN - 5
IMPORTANT Use the identication names
on the identication label of the product.
IMPORTANT Use these means of
identication whenever you contact
an authorized service workshop.
IMPORTANT example of the
declaration of conformity can be found
on the last pages of the manual.
3.4 MAIN COMPONENTS
The machine is made up of the
following main components (g. 1 ):
A. Chassis
B. Engine
C. Fuel tank
D. Handle
E. Dashboard
F. Brush safety guard
G. Brush
H. Small wheels
I. Wheel
 Fixing accessories equipment
K. Lights (optional)
L. Electric starter plug
4. ASSEMBLY
For storage and transport purposes, some
components of the machine are not installed
in the factory and have to be assembled after
unpacking. Follow the instructions below.
Unpacking and completing the
assembly should be done on a at and
stable surface, with enough space for
machine handling and its packaging,
always making use of suitable equipment.
Do not use the machine until all the
indications provided in the “ASSEMBLY”
section have been carried out.
IMPORTANT The machine is
supplied without engine oil or fuel.
4.1 ASSEMBLY COMPONENTS
The packaging holds the components needed
for assembly (g. 3 ) listed in the following table:
Pos. Description Q.ty
A Handle with pre-installed rods and wires 1
B Handle fastening screws 4
C Handle fastening bolts 4
D Funnel 1
E Oil extension hose 1
F Spark plug removal key 1
G Nuts and bolts 1
4.1.1 
1. Cautiously open the packaging, paying
attention not to lose components.
2. Consult the documentation in the
box, including these instructions.
3. Remove all the unassembled
parts from the box.
4. Remove the machine from the box.
5. Dispose of the box and packaging in
compliance with local regulations.
4.2 FORWARD AND BRUSH
CONTROL CABLE ASSEMBLY
Couple the cable eyelet to the
specic opening (g. 5 ).
NOTE The cables are already pre-
assembled on the dashboard.
4.3 HANDLE ASSEMBLY
The handle is delivered with the dashboard
already assembled. The machine handle
assembly screws, gear control fastening
screws and nuts and bolts to secure the brush
directional control are delivered in a separate
package found in the machine packaging.
Install as follows:
1. Bring the two tubes at the ends of the handle
(g. 6.A) up to the support (g. 6.B).
Insert the spacers (g. 6.C) and align
the holes, taking into account the
correct diameter (smaller cavity pointing
out, bigger cavity pointing in).
2. Insert the screws in the holes and
secure in place with the nuts.
4.3.1 
1. Screw the grips onto the threaded
rod of the gear lever (g. 9.A) and the
threaded rod of the brush adjustment
lever (g. 9.B) accordingly.
2. Tighten the xing nut.
