STIHL 019 T 14
• Fit the short circuit and ground
wires (pull them downward and out
of handle as far as possible) in the
grommet and close the grommet.
- Connect short circuit and ground
wires to ignition module.
- Fit throttle trigger - see 8.1.
- Fit the worm with drive spring in
position.
- Install the clutch - see 3.2.
• Remove the spark arresting screen.
- Clean the spark arresting screen or
fit a new one if necessary.
• Remove the cover plate.
Muffle
r
- Remove the engine - see 4.1.
• Take out the screws.
- Remove the muffler.
Reassemble in the reverse
sequence.
- Tighten screws to 7.0 Nm
(5.2 Ibf.ft).
- Install the engine - see 4.2.
Spark arresting screen
• Take out the screw.
• Fit the intake pipe (1) in the
intake casing (2).
4.3 Exhaust Muffler/Spark Arresting Screen
