0458-824-8621-B
21
English
16 Checking the Controls
To switch the blower on:
► Unlock the retaining latch (1) by pushing it forward with
your thumb. Hold it in this unlocked position.
► While holding the retaining latch, squeeze the trigger
switch (2) with your index finger.
The blower will activate.
The motor will not switch on unless the retaining latch is
pushed forward and the trigger switch is pressed at the
same time. Once the trigger switch is activated, you may
release the retaining latch. Holding the Ergo-Lever (3) down
keeps the trigger switch unlocked.
The further the trigger switch is depressed, the stronger the
blowing force.
If you releases the trigger switch and Ergo-Lever, you have
to unlock the tool again with the retaining latch.
15.2 Switching Off
WARNING
To reduce the risk of personal injury from unintended
activation or unauthorized use, switch off the motor and
remove the battery before transporting or putting the blower
down.
To switch the blower off:
► Release the trigger switch and Ergo-Lever so that the
trigger switch springs back to the locked position. In the
locked position, activation of the trigger switch is once
again blocked by the retaining latch.
16.1 Testing the Controls
Before starting work, confirm that the retaining latch (1),
Ergo-Lever (2) and the trigger switch (3) are undamaged
and functioning properly.
Retaining Latch (1), Ergo-Lever (2) and Trigger Switch (3)
WARNING
To help reduce the risk of injury from blown objects, always
wear proper eye protection while testing the controls. Keep
bystanders at least 17 ft. (5 m) away.
To test the controls:
► Remove the battery.
► Attempt to depress the trigger switch.
If the trigger switch can be depressed without first
unlocking the retaining latch by pushing it forward, take
the blower to an authorized STIHL servicing dealer to be
repaired before use.
1
3
2
0000-GXX-9903-A0
16 Checking the Controls
3
2
1
0000-GXX-2383-A1
