Positionconrodwithmarking
facinggearwheel.
•
Fitthrustplatewithfoldedcor-
nerspointingtowardsconrod.
-Useanewgasket.
-Torquescrewsingearboxcover
downto3.5Nm.
•
Removescrewplugfromgear-
boxcover.
•
Screwintubeofgreaseandroll
ituptothenextgradationonthe
tubescale.Thisforcesapprox.
20gofgreaseintothegearbox.
Note:UseSTIHLmulti-purpose
grease-see13.2-tolubricatethe
gearbox.
-Removecuttingblades,see12.2.
•
Removegearwheelfromgear
housing.
•
Removeconrodfromgear
housing.
•
Removethrustplatefromgear
housing.
Thepartsarefittedinreverse
order.
392RA196
VA
392RA199
VA
392RA200
VA
12.3 Gearwheel
392RA201
VA
392RA197
VA
392RA198
VA
392RA202
VA
