FR 480 C
English
24
Adjusting the harness straps
A Pull the ends of the straps
downward to tighten the harness.
B Lift the tabs of the adjusters to
loosen the straps.
C Close and lock the quick-release
fastener by pushing it together.
D Squeeze the hooks to open the
quick-release fastener.
Fitting the Backpack
N Close the waist belt (1) and adjust it
so that it fits snugly against your hip.
N Adjust the harness straps (2) to the
correct length.
N Use the straps (3) to adjust the
harness to suit your size.
The back padding must fit firmly and
securely against your back.
Removing the Backpack
N Open the quick-release fastener on
the waist belt.
N Loosen the harness straps by lifting
the sliding adjusters and then take
off the backpack.
Fitting the Backpack
A
B
271BA047 KN
C
D
271BA048 KN
1
2
3
3
2
271BA049 KN
