Stihl FS 111 User Manual

FS 111, FS 111 R
English
31
WARNING
Never remove the cap by turning it
directly to the open position. First allow
the power tool to cool adequately and
then release any residual pressure by
slowly turning the cap approximately
1/2 turn counter-clockwise. Never
attempt to remove the cap while the
engine is still hot or running.
Refueling
Take care not to spill fuel while fueling
and do not overfill the tank – leave
approximately 1/2" (13 mm) air space.
Closing
WARNING
An improperly tightened fuel filler cap
can loosen or come off and spill
quantities of fuel. To reduce the risk of
fuel spillage and fire from an improperly
installed fuel cap, tighten the fuel filler
cap by hand with as much force as
possible:
N If your fuel cap still does not tighten
properly, it may be damaged or
broken. Stop using the power tool
and take it to your authorized STIHL
dealer for repair or replacement.
The type and style of the
harness/shoulder strap depend on the
market.
The use of the shoulder strap is
described in the chapter on "Approved
Combinations of Cutting Attachment,
Deflector, Handle and Harness".
Shoulder Strap
N Put on the shoulder strap (1).
N Adjust the length of the strap so that
the carabiner (2) is about a hand’s
width below your right hip.
N Balance the machine – see
"Balancing the Machine".
002BA448 KN
Fitting the Harness
1
0000-GXX-0503-A0
2

Stihl FS 111 Specifications

General

Type	Brush cutter
Cordless	Yes
Head type	Blade
Handle type	U-type handle
Engine power	1.45 hp
Product color	Black, Metallic, Orange
Number of strokes	4
Sound power level	108 dB
Fuel tank capacity	0.71 L
Vibration emission	5.3 m/s²
Engine displacement	31.4 cm³
Sound pressure level	96 dB
Cutting diameter (max)	- mm
Power source	Gasoline

Weight and Dimensions

Length	1800 mm
Weight	5800 g
