Stihl FS 111 User Manual

FS 111, FS 111 R
English
35
As soon as the engine runs
N Press down the throttle trigger
lockout and open the throttle – the
choke knob moves to the run
position F. After a cold start, warm
up the engine by opening the
throttle several times.
WARNING
There is a risk of injury if the cutting
attachment runs when the engine is
idling. Adjust the carburetor so that the
cutting attachment does not run when
the engine is idling – see “Adjusting the
Carburetor”.
Your machine is now ready for
operation.
Stopping the Engine
N Depress the momentary contact
stop switch – the engine stops –
release the stop switch – it springs
back to the run position.
Other Hints on Starting
Engine stalls in cold start position g or
under acceleration.
N Move the choke knob to < and
continue cranking until the engine
runs.
Engine does not start in warm start
position <
N Move the choke knob to g and
continue cranking until the engine
runs.
If the engine does not start
N Check that all settings are correct.
N Check that there is fuel in the tank
and refuel if necessary.
N Check that the spark plug boot is
properly connected.
N Repeat the starting procedure.
Engine is flooded
N Move the choke knob to F and
continue cranking until the engine
runs.
Fuel tank run until completely dry
N After refueling, press the manual
fuel pump bulb at least five times –
even if the bulb is already filled with
fuel.
N Set the choke lever to suit the
engine temperature.
N Now start the engine.
002BA664 KN

Stihl FS 111 Specifications

General

Type	Brush cutter
Cordless	Yes
Head type	Blade
Handle type	U-type handle
Engine power	1.45 hp
Product color	Black, Metallic, Orange
Number of strokes	4
Sound power level	108 dB
Fuel tank capacity	0.71 L
Vibration emission	5.3 m/s²
Engine displacement	31.4 cm³
Sound pressure level	96 dB
Cutting diameter (max)	- mm
Power source	Gasoline

Weight and Dimensions

Length	1800 mm
Weight	5800 g
