Stihl FS 120 R User Manual

FS 120, FS 120 R, FS 250
English
38
Repeat the above procedure as
necessary until both lines reach the
limiter blade on the deflector.
Rotating the spool from one stop to the
next advances about 4 cm (1 1/2 in) of
fresh line.
Replacing Nylon Line
STIHL PolyCut
A length of nylon line can be fitted to the
PolyCut in place of the cutting blades.
STIHL DuroCut, STIHL PolyCut
WARNING
To reduce the risk of injury, always shut
off the engine before refilling the mowing
head.
N Fit nylon line in the mowing head as
described in the instructions
supplied.
Replacing Cutting Blades
STIHL PolyCut
Always check the mowing head for signs
of wear before installing new cutting
blades.
WARNING
If there are signs of serious wear,
replace the complete mowing head.
The thermoplastic cutting blades are
referred to as "blades" in the following.
The mowing head is supplied with
illustrated instructions for replacing the
blades. Keep the instructions for the
mowing head in a safe place.
WARNING
To reduce the risk of injury, always shut
off the engine before installing the
blades.
N Remove the mowing head.
N Replace blades as shown in the
illustrated instructions.
N Mount the mowing head on the
machine.
Changing the Fuel Pickup Body
Change the fuel pickup body every year:
N Drain the fuel tank.
N Use a hook to pull the fuel pickup
body out of the tank and take it off
the hose.
N Push the new pickup body into the
hose.
N Place the pickup body in the tank.
Inspection and Maintenance
by User
250BA072 KN
