19 Specifications

19.1 STIHL FS 240 R, 260 R Brush‐

cutter

–

Displacement:

–

FS 240 R: 37.7 cm³

–

FS 260 R: 41.6 cm³

–

Engine power acc. to ISO 8893:

–

FS 240 R: 1.7 kW (2.3 hp) at 8500 rpm

–

FS 260 R: 2.0 kW (2.7 hp) at 9000 rpm

–

Idle speed : 2,800 rpm

–

Max. output shaft speed: 7930 rpm

–

Approved spark plug: NGK CMR6H from

STIHL

–

Electrode gap of the spark plug: 0.5 mm

–

Dry weight without cutting attachment and

deflector: 6.6 kg

–

Length without cutting attachment: 1865 mm

–

Max. fuel tank capacity: 750 cm³ (0.75 l)

19.2 Sound Values and Vibration

Values

The K-value for the sound pressure levels is

2 dB(A). The K-value for the sound power levels

is 2 dB(A). The K-value for vibration level is

2 m/s².

Using with a mowing head

–

Sound pressure level L

measured according

to ISO 22868:

–

FS 240 R: 99 dB(A)

–

FS 260 R: 100 dB(A)

–

Sound power level L

measured according to

ISO 22868:

–

FS 240 R: 108 dB(A)

–

FS 260 R: 109 dB(A)

–

Vibration level a

measured according to

ISO 22867:

–

FS 240 R control handle: 5.7 m/s².

–

FS 240 R left handle: 5.6 m/s².

–

FS 260 R control handle: 6.8 m/s².

–

FS 260 R left handle: 6.1 m/s².

Using with a metal cutting attachment

–

Sound pressure level L

measured according

to ISO 22868:

–

FS 240 R: 99 dB(A)

–

FS 260 R: 100 dB(A)

–

Sound power level L

measured according to

ISO 22868:

–

FS 240 R: 110 dB(A)

–

FS 260 R: 110 dB(A)

–

Vibration level a

measured according to

ISO 22867:

–

FS 240 R control handle: 5.8 m/s².

–

FS 240 R left handle: 4.3 m/s².

–

FS 260 R control handle: 7.0 m/s².

–

FS 260 R left handle: 5.0 m/s².

For information on compliance with Employers'

Vibration Directive 2002/44/EC see

www.stihl.com/vib.

19.3 REACH

REACH is an EC regulation and stands for the

Registration, Evaluation, Authorisation and

Restriction of Chemical substances.

For information on compliance with the REACH

regulation see www.stihl.com/reach.

19.4 Exhaust Emissions

The CO

value measured in the EU type appro‐

val procedure is specified at www.stihl.com/co2

in the product-specific technical data.

The measured CO

value was determined on a

representative engine in accordance with a

standardised test procedure under laboratory

conditions and does not represent either an

explicit or implied guarantee of the performance

of a specific engine.

The applicable exhaust emission requirements

are fulfilled by the intended usage and mainte‐

nance described in this instruction manual. The

type approval expires if the engine is modified in

any way.

20 Combinations of Cutting Attachments, Deflectors and Carrying

Systems

20.1 Combinations of Cutting Attachments, Deflectors and Carrying Systems

Cutting attachment Deflector Barrier bar Carrying System

–

AutoCut 25-2 mowing head

–

AutoCut 27-2 mowing head

–

AutoCut 36-2 mowing head

–

Guard for mow‐

ing heads

–

optional

–

Shoulder strap

–

Full harness with quick-

release system

19 Specifications English

0458-891-0101-A 21

Questions and Answers:

Need help?

Do you have a question about the Stihl FS 240 R and is the answer not in the manual?

Stihl FS 240 R Specifications

General

Type	String trimmer
Cordless	Yes
Head type	Nylon line
Handle type	D-loop handle
Engine power	2.3 hp
Product color	Black, Metallic, Orange
Rotational speed	8500 RPM
Number of strokes	2
Sound power level	110 dB
Fuel tank capacity	0.75 L
Engine displacement	37.7 cm³
Sound pressure level	99 dB
Cutting diameter (max)	420 mm
Power source	Gasoline
