Stihl FSA 60 R User Manual

17 Maintenance
17.1 Maintenance Intervals
The maintenance intervals are dependent on the
environmental and operating conditions. STIHL
recommends the following maintenance inter‐
vals:
Every 12 months
► Have the trimmer checked by a STIHL servic‐
ing dealer.
18 Repairing
18.1 Repairing the Trimmer, Battery
and Charger
The trimmer, cutting attachment, battery and
charger are not user serviceable.
► If the trimmer or cutting attachment is dam‐
aged: Do not use your trimmer or cutting
attachment and contact your STIHL servicing
dealer.
► If the battery has a malfunction or is damaged:
Replace the battery.
► If the charger has a malfunction or is dam‐
aged: Replace the charger.
► If the connecting cable has a malfunction or is
damaged: Do not use the charger and have
connecting cable replaced by a STIHL servic‐
ing dealer.
19 Troubleshooting
19.1 Troubleshooting Trimmer or Battery
Condition LEDs on Bat‐
tery
Cause Remedy
Trimmer does
not start when
switched on.
1 LED flashes
green.
Battery has low
charge.
► Charge the battery.
1 LED glows
red.
Battery too hot or too
cold.
► Remove the battery.
► Allow battery to cool down or warm up.
3 LEDs flash
red.
There is a malfunction
in the trimmer.
► Remove the battery.
► Clean contacts in battery compartment.
► Fit the battery.
► Switch on the trimmer.
► If 3 LEDs continue to flash red: Do not
use your trimmer and contact your
STIHL dealer for assistance.
3 LEDs glow
red.
Trimmer is too hot. ► Remove the battery.
► Allow trimmer to cool down.
4 LEDs flash
red
There is a malfunction
in the battery.
► Remove battery and insert it again.
► Switch on the trimmer.
► If 4 LEDs continue to flash red: Do not
use the battery and contact your STIHL
dealer for assistance.
No electrical contact
between trimmer and
battery.
► Remove the battery.
► Clean contacts in battery compartment.
► Fit the battery.
Trimmer or battery
damp.
► Allow trimmer or battery to dry.
Trimmer cuts out
during operation.
3 LEDs glow
red.
Trimmer is too hot. ► Remove the battery.
► Allow trimmer to cool down.
There is a electrical
malfunction.
► Remove battery and insert it again.
► Switch on the trimmer.
Trimmer runtime
is too short.
Battery not fully
charged.
► Fully charge the battery.
17 Maintenance English
0458-832-0121-B. VA0.B21. 17

Stihl FSA 60 R Specifications

General

Type	Brush cutter
Cordless	Yes
Head type	Blade
Handle type	D-loop handle
Product color	Orange, Black, White
Uncertainty K	2 m/s²
Sound power level	91 dB
Vibration emission	3.7 m/s²
Sound pressure level	77 dB
Cutting diameter (max)	350 mm
Power source	Battery
Operating time	30 min
Battery voltage	36 V

Weight and Dimensions

Length	1680 mm
Weight	3100 g
