FSE 31, FSE 41
English
13
The voltage and frequency of the
machine (see rating plate) must match
the voltage and frequency of the power
connection.
The minimum fuse protection of the
power connection must comply with the
specifications – see "Specifications".
The machine must be connected to the
power supply via an earth-leakage
circuit breaker to disconnect the power
supply if the differential current to earth
exceeds 30 mA.
The power connection must correspond
to IEC 60364 and relevant national
regulations.
Extension cord
The design of the extension cord must at
least fulfill the same features as the
connecting cord on the machine.
Observe the design marking (type
designation) on the connecting cord.
The cores in the cord must have the
following minimum cross-section
depending on the mains voltage and
cord length.
N Insert the plug (1) into the extension
cord coupling (2).
Strain Relief
The strain relief (cord retainer) protects
the connecting cord against damage.
N Make a loop in the extension cord.
N Pass the loop (3) through the
opening (4).
N Slip the loop (3) over the hook (5)
and pull it tight.
N Connect the extension cord plug to
a properly installed wall outlet.
N Make sure you have a secure and
balanced footing.
N Hold your trimmer with both hands –
right hand on the control handle –
left hand on the assist handle.
N Stand upright – hold the trimmer in a
relaxed position and always on right
side of your body.
N Make sure the cutting attachment is
not touching the ground or any other
objects.
N Squeeze the trigger switch (1).
Connecting to Power Supply
Cord length Minimum cross-
section
220 V – 240 V:
Up to 20 m 1.5 mm
2
20 m to 50 m 2.5 mm
2
100 V – 127 V:
Up to 10 m AWG 14 / 2.0 mm
2
10 m to 30 m AWG 12 / 3.5 mm
2
Switching On
