Stihl FSE 71 User Manual

13FSE 60, FSE 71, FSE 81
English
Adjusting Nylon Line
STIHL AutoCut mowing head
: Hold the rotating mowing head
horizontal to the ground – tap it on
the ground – about 3cm fresh line is
advanced.
: The blade (1) on the deflector (2)
trims surplus line to the correct
length. Avoid tapping the head more
than once.
Line feed operates only if both lines
are at least 2.5cm long.
If the nylon lines are shorter than 2.5cm:
: Switch off the machine.
: Unplug the power cord from the
power supply.
: Turn the machine in its back.
: Push home the cap on the spool as
far as stop.
: Pull the ends of the nylon line out of
the spool to the required length.
If the spool is empty, see “Replacing
Nylon Line”.
Removing the Mowing Head
STIHL AutoCut
: Hold the mowing head steady.
: Unscrew the cap counterclockwise.
Replacing Cutting Line
STIHL AutoCut
See chapter on “Replacing Nylon Line”.
Mains voltage and operating voltage
must be the same.
The machine must be connected to the
power supply via a ground-fault circuit
interrupter.
The mains connection must comply with
IEC 60364 and country-specific
regulations.
Check the minimum conductor cross
section required for extension cords.
1
282BA004 KN
2
Cord length Cross section
up to 25 m 1.0 mm
2
25 m to 50 m 1.5 mm
2
Connecting to Power
Supply

Stihl FSE 71 Specifications

General

Type	Brush cutter
Head type	Nylon line
Handle type	D-loop handle
Product color	Orange, White
Sound power level	93 dB
Power cable length	0.5 m
Vibration emission	3.3 m/s²
Automatic line feed	Yes
Sound pressure level	82 dB
Cutting diameter (max)	350 mm
Power source	AC
AC input voltage	230 V

Weight and Dimensions

Length	1530 mm
Weight	4000 g
