English 3 Main Parts
5 Blade Scabbard
Covers the cutting blades to reduce the risk of injury from
inadvertent contact during transportation and storage.
6 Blade Adjustment Release
Unlocks the cutting blades to allow angle adjustment.
7 Blade Adjustment Grip
Used to set the cutting blades to the desired angle.
8 Battery Compartment
Holds the battery.
9 Locking Lever
Secures the battery in the battery compartment.
10 Ergo-Lever
Holds the retaining latch in the unlocked position.
11 Retaining Latch
Locks/unlocks the trigger switch.
12 Trigger Switch
Switches the motor on and off.
13 Control Handle
Handle for the operator's rear hand.
14 Carrying Ring
For connecting a harness to the hedge trimmer.
15 Push Button
Activates the battery's LEDs.
16 Battery
Supplies electrical power to the motor.
17 Battery LEDs
Indicate the battery's state of charge and display error
messages regarding potential malfunctions in the battery
or power tool.
18 Shoulder Strap
Helps to support the hedge trimmer when working.
# Rating Plate
Contains electrical information and the product's serial
number.
3.2 HLA 86 Hedge Trimmer and Battery
1 Carrying Ring
For connecting a harness to the hedge trimmer.
2 Front Handle
Handle for the operator's front hand.
3Drive Tube
Hedge trimmer shaft.
4 Cutting Blades
Steel blades for cutting hedges, shrubs and bushes.
5 Blade Scabbard
Covers the cutting blades to reduce the risk of injury from
inadvertent contact during transportation and storage.
1
2
3
11
12
4
8
7
5
#
13
14
10
9
6
18
0000097078_001
16
15
#
17
