Stihl MS 192 T Manual

18 MS 192 T
Bumper strips are fitted on the
engine housing to guide the saw
chain.
Worn bumper strips must be
replaced, otherwise the engine
housing may be damaged.
Remove the sprocket cover and bar
and chain, b 5.1
: Prise off the bumper strips (1)
with a suitable tool.
217RA071 TG
1
1
: Insert the bumper strips so that
the peg is aligned in the recess
(arrows).
– Reassemble remaining parts in
reverse order.
217RA083 TG
– Troubleshooting, b 4.1
– Remove the sprocket cover and
bar and chain, b 5.1
: Release the twist lock (arrow).
: Remove carburetor box cover (1)
to the rear.
217RA008 TG
1
: Apply a suitable tool to the tab
(arrow) to prise the boot off the
spark plug (1).
1
217RA009 TG
: Unscrew the spark plug (1).
1
217RA010 TG
: Push the locking strip (1)
0000 893 5903 into the spark
plug hole so that "OBEN-TOP"
faces down.
1
217RA011 TG
: Unscrew the clutch (1).
The clutch has a left-hand thread.
1
217RA012 TG
5.5 Bumper Strips 6. Clutch
