91MS 192 T
: Pull the fuel return line (1) out of
the guides and flange (arrow).
217RA302 TG
1
: Pull the fuel hose (1) out of the
hose on the fuel pump.
1
217RA349 TG
: Pull the fuel hose (1) out of the
guides and flange (arrow).
217RA303 TG
1
: Pull the elbow connectors (3) off
the hoses.
– Check the fuel hose (1), fuel
return line (2) and elbow
connectors (3) and replace them
if necessary.
217RA307 TG
3
3
2
1
– Reassemble parts in reverse
order.
– Remove the pick-up body,
b 14.7.1
: Prise off the flange (1) with a
suitable tool.
217RA293 TG
1
: Pull the fuel suction hose (1) out
of the tank.
– Examine the fuel suction hose
and replace it if necessary,
217RA287 TG
1
: Push the fuel suction hose (1)
into the hole in the fuel tank.
1
217RA288 TG
: Align the flange (1) and press it
into the fixture on the housing
until it rests against the housing.
1
217RA289 TG
