Stihl MS 310 User Manual

29MS 290, MS 310, MS 390
: Use press sleeve (1)
1127 893 2400 to install the
“soft” oil seal.
– Wait about one minute, then
rotate the crankshaft.
– Install the flywheel, b 7.3
209RA090
VA
1
Install all other parts in the reverse
sequence.
: Pull off the spark plug boot (1).
: Pull the ignition lead (3) out of the
retainer (2) and guides (arrows).
209RA109
2
VA
3
1
: Take out the screws (arrows).
: Lift the shroud (1) up a little and
remove it to the rear.
209RA183
VA
1
: If necessary, unclip the
shutter (1).
Install in the reverse sequence.
209RA184
1
VA
Machines up to 2001
: Push the tank vent (1) into its seat
(arrow) in the shroud (2).
209RA192
VA
2
1
6.4 Shroud
