41MS 290, MS 310, MS 390

– Use a pointed tool to pierce the

center of the ignition lead’s

insulation, about 15 mm from the

end of the lead.

: Pinch the hook of the leg spring

into the center of the lead (arrow).

176RA160

: Pull the lead back into the spark

plug boot so that the leg spring

locates properly inside it (arrow).

171RA146

Install all other parts in the reverse

sequence.

– Troubleshooting – b 4.4

– Remove the ignition module,

b 7.1.2

: Pull the grommet (arrow)

downwards and off the ignition

lead.

209RA120

: Pull the ignition lead (1) upwards

and out of the tank housing.

– Remove the spark plug boot,

b 7.2

Install in the reverse sequence.

– Cut new ignition lead to a length

of 175 mm.

: Use a pointed tool to pierce the

center of the other end of the

ignition lead which screws into

the module.

176RA162

7.2.1 Ignition Lead
