MS 341, MS 361, MS 361 C
English
80
If there is a noticeable loss of engine
power
Removing the carburetor box cover
N Move the Master Control lever to
stop position (0).
N Loosen the twist lock (1) in the
direction of the arrow.
N Remove the carburetor box
cover (2).
Removing the air filter
N Clean away loose dirt from around
the filter.
N Remove the filter.
Cleaning the air filter
N Knock the filter out on the palm of
your hand or blow it clear with
compressed air from the inside
outwards.
If filter is caked with dirt:
N Wash the filter in STIHL special
cleaner (special accessory) or a
clean, non-flammable solution (e.g.
warm soapy water) and then dry.
N Always replace damaged filters.
Installing the air filter
N Place the filter (3) in position
(arrows).
N Fit the carburetor box cover.
General Information
The carburetor comes from the factory
with a standard setting.
This setting provides an optimum fuel-air
mixture under most operating
conditions.
With this carburetor it is only possible to
correct the adjusting screws within fine
limits.
Standard setting
N Shut off the engine
N Check the air filter and clean or
replace if necessary.
N Check the spark arresting screen
(country-specific) in the muffler and
clean or replace if necessary.
Cleaning the Air Filter
To avoid damaging the filter, do
not use tools for removing and
installing the air filter.
1
213BA009 KN
2
Do not use a brush to clean the
fleece filter.
Adjusting the Carburetor
If the setting is too lean there is a
risk of engine damage due to
insufficient lubrication and
overheating.
