0458-716-8621-E
57
English
26 Specifications
26.1 STIHL MSA 120 C, MSA 140 C
MSA 120 C
Intended for household use.
– Approved battery type: STIHL AK series
– Weight without battery, guide bar and saw chain:
5.1 lbs. (2.3 kg)
– Maximum oil tank volume: 3.7 oz. (0.11 l)
MSA 140 C
Intended for household use.
– Approved battery type: STIHL AK series
– Weight without battery, guide bar and saw chain:
4.9 lbs. (2.3 kg)
– Maximum oil tank volume: 3.7 oz. (0.11 l)
26.2 Chain Sprockets
MSA 120 C
The following chain sprockets are available for this model
chain saw:
– 6-tooth for 1/4" PICCO pitch
MSA 140 C
The following chain sprockets are available for this model
chain saw:
– 6-tooth for 1/4" PICCO pitch
26.3 Minimum Groove Depth of Guide Bars
The minimum groove depth of a guide bar depends on the
pitch of the guide bar.
– Minimum groove depth for 1/4" PICCO pitch guide bars:
0.157 in. (4 mm)
26.4 Depth Gauge Setting
The depth gauge setting of a saw chain depends on the pitch
of the chain.
– Depth gauge setting for 1/4" PICCO pitch chains:
0.018 in. (0.45 mm)
26.5 STIHL AK Series Battery
Approved charger type: STIHL AL 101, AL 300 or AL 500
series.
– Battery technology: Lithium-Ion
– Voltage: 36 V
– Rated capacity in Ah
1
: See rating plate
– Stored energy in Wh
2
: See rating plate
– Weight in kg: See rating plate
– Permissible ambient temperature range during use or
storage: 14 °F to 122 °F (- 10 °C to 50 °C)
For a complete list of approximate charging times, see
www.stihl.com/charging-times.
For a complete list of approximate battery runtimes, see
www.stihl.com/battery-life.
26.6 STIHL AL 101
– Mains voltage: 120 V
– Rated current: 1.3 A
26 Specifications
1
Rated capacity calculated pursuant to IEC 61960. Usable energy
available to the operator will be less.
2
The battery is marked with its stored energy as provided by the cell
manufacturer. Usable energy available to the operator will be less.
