No. Part name Part No. Use
1 Hook 5910 890 2900 Removing injector from safety control block housing
Drawing valve body out of safety control block
2 Assembly device 4726 890 2200 Fitting high-pressure cups in valve block
(assembly arbor and sleeve) with support rings
Installing oil seals in pump housing
3 Assembly arbor 4112 893 2401 Forcing oil seal into drive housing
4 Extractor 4703 890 4500 Drawing ball bearings off drive shaft
5 1/4" hexagon socket wrench Screw plug in drive housing
6 Torque wrench 5910 890 0300
7 Torque wrench 5910 890 0310
8 Test pressure gauge 5910 850 3205 Setting pressure control system
12.2 Service accessories
No. Part name Part No. Use
1 Special grease, waterproof, 0781 145 3516 O-rings, high-pressure cups,
50 g tube sliding surfaces in contact with water
2 Locking paint, standard Adjusting nut and adjusting screw
for pressure setting on control piston
12. SPECIAL TOOLS AND SERVICE TOOLS
12.1 Special tools
RE 140 K, 160 K 31
