SG 11 , SG 11 PLUS
English
11
6. Pick-up Tube Liquid.
Feeds liquid from tank to the spray
nozzle.
7. Piston Seal
Seals the piston to the pump
cylinder for producing pressure.
8. Sealing Pump Cylinder.
Seals the pump cylinder to the
cover.
9. Pump Cylinder.
Houses the piston for generating
pressure.
10 Sealing Ring.
Seals the the tank when the cover is
closed.
11. Container.
Contains the spray solution.
12. Hollow Cone Nozzle.
Produces a conical spray pattern.
Model SG 11 PLUS
13. Pick-up Tube Cap.
Protects the valve from liquid.
14. Pick-up Tube Air.
Feeds air from pump cylinder to the
top of the tank.
15. Adjustable Nozzle.
Adjustable from conical to full jet
spray pattern.
Observe all country-specific waste
disposal rules and regulations.
STIHL products must not be thrown in
the garbage can. Take the product,
accessories and packaging to an
approved disposal site for environment-
friendly recycling.
Contact your STIHL servicing dealer for
the latest information on waste disposal.
Specifications
Max. capacity: 1.5 l (50.7 fl.oz)
Tank volume: 1.9 l (64.2 fl.oz)
Max. pressure: 3 bar (43.5 PSI)
Max. temperature: 30°C (86°F)
Spray rate at 3 bar
(43.5 PSI):
600 cc/min
(36.6 cu.in/min)
Weight: 0.47 kg (1.0 lbs)
Disposal
