Sub-Zero Designer Series User Manual

subzero.com | 13
Freezer Storage
FREEZER STORAGE DRAWERS
To remove a freezer drawer:
1 Pull the drawer open until it stops.
2 Locate the two plastic tabs at the front of the drawer
behind the bottom corners.
3 Pull the tabs forward, then lift up and out. Refer to the
illustrations below.
If the door opening is limited to 90°, the top drawer must
be removed before removing the middle or lower drawer.
To install a freezer drawer:
1 Push the drawer slides in.
2 Align the drawer with the slides and push back until it
stops.
3 Press down on the front of the drawer to engage the
slides.
TAB
Column freezer drawer Freezer drawer tab
ICE BIN
To remove the ice bin (column model):
1 Pull the freezer drawer open until it stops.
2 Lift the ice bin out. Refer to the illustration below.
To remove the ice bin (tall and drawer models):
1 Pull the freezer drawer open until it stops.
2 Lift the ice bin out. Refer to the illustration below.
Storage
Column ice bin Tall and drawer ice bin
