Subaru EA190V Service Manual

6
1-1-2 Model & serial number
1-2 Specification
 Model
Specification
EA190
L×W×H
(not including crankshaft output terminal)
425×360×290mm
Dry Weight 11.5 or 14.5kg
Engine Type
single cylinder horizontal,4-stroke,（OHC）
Displacement 189ml
Bore × Stroke 68mm×52mm
Theoretical Maximum Power 3.72kW/3,600r/min
Recommended Using Power 3.5 kW/3,400r/min
Maximum Torque 11.2N·m /2,500r/min
Fuel Consumption 395g/Kw·h
Cooling System Forced air
Ignition System capacitance discharge type
PTO Shaft Rotation vertical shaft output
Engine model
Serial number

Subaru EA190V Specifications

General

Compression Ratio	8.5:1
Lubrication System	Splash
Ignition System	Transistorized Magneto Ignition
Starting System	Recoil Starter
Oil Capacity	0.6 liters
Fuel Type	Unleaded gasoline
Engine Oil Type	SAE 10W-30
Engine Type	4-Stroke, Air Cooled, OHV
Fuel Tank Capacity	3.6 L
