Subaru EH72 FI User Manual

- 10 -
23) GOVERNOR LEVER
Attach governor rod and rod spring
between governor lever and throttle body
throttle lever, and insert the governor lever
to governor lever shaft. Tighten locking bolt
temporarily.
24) SPEED CONTROL LEVER
(1) Install speed control bracket onto intake
manifold.
(2) Attach return spring, spacer, friction
washer, wing nut, etc. to speed control lever
as shown in the ilustration.
(3) Connect governor spring to governor lever
and speed control lever.
GOVERNOR
SHAFT
GOVERNOR
LEVER
ROD SPRING
GOVERNOR
ROD
ROD HOLDER
THROTTLE LEVER
A
L
R
ROD
SPRING
GOVERNOR ROD ROD HOLDER
Turn the rod holder
counter clockwise
and fix it.
Then hook the rod
spring as shown
on the diagram.
VIEW
A
STOP PLATE
SPRING WASHER
SPEED CONTROL
LEVER
M6 FLANGE
BOLT
M6 SELF LOCK
NUT
FRICTION
WASHER
FRICTION
WASHER
BRACKET UNIT,
speed control
E





D
*29(5125
*($5
*29(5125635,1*
$'-867,1*
6&5(:
63(('&21752//(9(5
*29(5125
/(9(5
*29(5125
52'
52'635,1*
&/($1(5$'$37(5
7+5277/(%2'<
)8//23(1
)8//&/26(
/2&.187
+,*+63(('
/2:63(('
$
%
,17$.(0$1,)2/'
/ 5
Fitting location of governor rod and governor spring
50 Hz 60 Hz
EH72 FI NA A-2(a)
