10 OF 12
PART NUMBER
H001SXC100
ISSUE
-
DATE
10 Jan 2018
SUBARU OF AMERICA
PANEL RE-ASSEMBLY
8
1. Plug the yellow electrical connector into the airbag/knee bolster. Verify that the yellow connector is fully seated.
Failure to seat the connector lock could result in the instrument cluster airbag light remaining illuminated. Reinstall
the airbag/knee bolster and torque the two (2) 10mm nuts to 7.5 Nm +/- 2 Nm (0.76 Kgf-m +/- 0.2 Kgf-m, 5.5 ft-lbs
+/- 1.5 ft-lbs).
2. Plug in any previously removed connectors and re-install the driver’s side dashboard panel by engaging the seventeen
(17) pressure clips.
3. Re-install the one (1) Phillips screw on the lower right side of the dashboard panel.
4. Re-install the left side dashboard panel by engaging the six (6) pressure clips.
5. Re-connect the glove box lamp connector to the lamp on the glove box inner cover. Re-install the glove box inner
cover by engaging the six (6) pressure clips and secure with six (6) Phillips screws.
6. Re-install the passenger’s side ornament panel by engaging the eight (8) pressure clips.
7. Re-install the right side dashboard panel by engaging the six (6) pressure clips.
8. Re-install the glove box and strut.
9. At the end of the installation, insert the Quick Reference Cards into the Owner’s Information Kit.
SYSTEM POWER-UP
1. After all the connections are complete, re-connect the vehicle’s negative battery terminal. Using a 10mm socket/
torque wrench, tighten the 10mm nut to 7.5 Nm +/- 2 Nm (0.76 Kgf-m +/- 0.2 Kgf-m, 5.5 ft-lbs +/- 1.5 ft-lbs).
2. Start the vehicle at least one (1) time using the ignition key prior to activating the remote engine start system. This
is required to allow the vehicle’s electronic systems to re-synchronize.
3. With the vehicle running via the ignition key, verify that the instrument cluster airbag light turns off. If the airbag light
remains on, refer to the vehicle service information for troubleshooting.
4. With the vehicle running via the ignition key, apply the brake pedal and shift the transmission out of park. Turn off
the engine and confi rm the ignition key cannot be removed from the ignition switch. If it can, confi rm the key lock
solenoid connector is connected and the delivery (test) mode fuse is removed, then re-check.
5. Refer to the vehicle Owner’s manual for the Power Window Reset Procedure to restore the power window functions.
9
