6-48
LIGHT BULB REPLACEMENT
The wattage rating of each bulb is
shown on the table below. When
replacing a burned out bulb, always
use the exact same wattage rating.
Using other than the specified rating
can result in overloading the electrical
system or premature failure of a bulb.
HEADLIGHT/POSITION LIGHT
To replace the headlight bulb and
position light bulb, perform the follow-
ing step:
To remove the instrument panel
assembly:
1. Remove the bolts and fasteners.
2. Push the instrument panel cover
at the circled place with thumb
and roll up the cover to unhook
the hook.
NOTICE
Failure to use a light bulb with the
correct wattage rating can over-
load the electrical system of your
motorcycle or cause the bulb to
burn out sooner.
Use only the light bulbs shown in
the chart as replacement bulbs.
Headlight 12V 60/55W (H4) × 2
Position light 12V 5W × 2
Turn signal light 12V 21W
Brake light/Taillight 12V 21/5W
License plate light 12V 5W
