0A-8 General Information:
Engine Supporting Points
S6JB0A0101006
WARNING
!
When using engine supporting device (1), be
sure to observe the followings.
Otherwise, not only deformation of vehicle
body and/or engine hook but also personal
injury may result.
• Apply supporting device at the specified
positions (2) indicated in figure
• Install supporting device taking a well-
balanced posture.
• Do not contact supporting device with
other parts than specified positions and
engine hooks.
• Do not remove engine rear mounting
(transfer mounting) while supporting.
• Set support device so that side force
applies to hook excessively.
Excessive side force will deform hook.
Vehicle Identification Number
S6JB0A0101007
The vehicle identification number is punched on the front
dash panel in engine room and it is also attached on the
left front top of instrument panel depending on vehicle
specification.
1
2
2
I5JB0A010005-02
I5JB0A010001-02
