0A-10 General Information:
Component Location
Warning, Caution and Information Label Location
S6JB0A0103001
The figure shows main labels among others that are attached to vehicle component parts.
When servicing and handling parts, refer to WARNING / CAUTION instructions printed on labels.
If any WARNING / CAUTION label is found stained or damaged, clean or replace it as necessary.
NOTE
Air bag labels are attached on the vehicle equipped with air bag system only.
I6JB0A010003-01
[A]: Petrol engine model 3. Degassing tank cap label 7. Jacking label
[B]: Diesel engine model 4. Engine cooling fan label 8. Parking (transfer) label (if equipped)
1. Smoke level label (diesel engine model) 5. Air bag label on sun visor 9. Side air bag label (Both RH and LH)
2. Radiator cap label 6. Air bag label and utility vehicle label on sun visor 10. Child seat label on instrument panel (if equipped)
