7-47
FUSE LIST
• 30A MAIN fuse protects all
electrical circuits.
• 10A HEAD-HI fuse protects
the headlight high beam and
speedometer.
• 10A HEAD-LO fuse protects
the headlight low beam.
• 15A IGNITION fuse protects
the cooling fan relay, oxygen
sensor, ECM, solenoid, fuel
pump relay, starter relay, side
stand relay, ignition coils and
canister purge solenoid (Cali-
fornia).
• 15A SIGNAL fuse protects the
speedometer, brake light and
horn.
• 10A FUEL fuse protects the
ECM, speedometer, fuel pump
and injectors.
• 15A FAN fuse protects the
cooling fan motor.
(SV650A)
• 30A ABS fuse protects ABS
system.
CATALYTIC CONVERTER
The purpose of the catalytic con-
verter is to minimize the amount
of harmful pollutants in your
motorcycle’s exhaust. Use of
leaded fuel in motorcycles
equipped with catalytic converters
is prohibited because lead deacti-
vates the pollutant-reducing com-
ponents of the catalyst system.
The converter is designed to last
the life of the motorcycle under
normal usage and when unleaded
fuel is used. Not special mainte-
nance is required on the con-
verter. However, it is very
important to keep the engine
properly tuned. Engine misfiring,
which can result from an improp-
erly tuned engine, may cause
overheating of the catalyst. This
may result in permanent heat
damage to the catalyst and other
motorcycle components.

Suzuki SV650 Specifications

General

Bore x Stroke	81.0 mm x 62.6 mm
Compression Ratio	11.2:1
Fuel System	Fuel injection
Transmission	6-speed constant mesh
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Front Tire	120/70ZR17M/C (58W), tubeless
Rear Tire	160/60ZR17M/C (69W), tubeless
Overall Length	2, 140 mm (84.3 in)
Overall Width	760 mm (29.9 in)
Overall Height	1, 090 mm (42.9 in)
Wheelbase	1, 445 mm (56.9 in)
Ground Clearance	135 mm (5.3 in)
Seat Height	785 mm (30.9 in)
Ignition	Electronic ignition (transistorized)
Starter	Electric
Final Drive	Chain
Engine Type	645cc, 4-stroke, liquid-cooled, DOHC, 90° V-twin
Rear Brakes	Hydraulic disc
Fuel Tank Capacity	14.5 L (3.8 US gal)
Curb Weight	198 kg (437 lbs)
