Suzuki SV650 User Manual

9-3
PROCEDURE FOR RETURNING
TO SERVICE
1. Clean the entire motorcycle.
2. Remove the oily rags from the
air cleaner intake and muffler
outlet.
3. Drain all the engine oil. Install
a new oil filter and fill the
engine with fresh oil as out-
lined in this manual.
4. Remove the spark plugs. Turn
the engine a few times. Rein-
stall the spark plugs.
5. Reinstall the battery by refer-
ring to the BATTERY section.
6. Make sure that the motorcycle
is properly lubricated.
7. Perform the INSPECTION
BEFORE RIDING as listed in
this manual.
8. Start the motorcycle as out-
lined in this manual.
CORROSION PREVENTION
It is important to take good care of
your motorcycle to protect it from
corrosion and keep it looking new
for years to come.
Important Information About
Corrosion
Common causes of corrosion
• Accumulation of road salt, dirt,
moisture, or chemicals in hard-
to-reach areas.
• Chipping, scratches, and any
damage to treated or painted
metal surfaces resulting from
minor accidents or impacts
from stones and gravel.
Road salt, sea air, industrial pollu-
tion, and high humidity will all con-
tribute to corrosion.
How to Help Prevent Corrosion
• Wash your motorcycle fre-
quently, at least once a month.
Keep your motorcycle as clean
and dry as possible.
• Remove foreign material
deposits. Foreign material
such as road salt, chemicals,
road oil or tar, tree sap, bird
droppings and industrial fall-
out may damage your motor-
cycle’s finish. Remove these
types of deposits as quickly as
possible. If these deposits are
difficult to wash off, an addi-
tional cleaner may be required.
Follow the manufacturer’s
directions when using these
special cleaners.

Suzuki SV650 Specifications

General

Bore x Stroke	81.0 mm x 62.6 mm
Compression Ratio	11.2:1
Fuel System	Fuel injection
Transmission	6-speed constant mesh
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Front Tire	120/70ZR17M/C (58W), tubeless
Rear Tire	160/60ZR17M/C (69W), tubeless
Overall Length	2, 140 mm (84.3 in)
Overall Width	760 mm (29.9 in)
Overall Height	1, 090 mm (42.9 in)
Wheelbase	1, 445 mm (56.9 in)
Ground Clearance	135 mm (5.3 in)
Seat Height	785 mm (30.9 in)
Ignition	Electronic ignition (transistorized)
Starter	Electric
Final Drive	Chain
Engine Type	645cc, 4-stroke, liquid-cooled, DOHC, 90° V-twin
Rear Brakes	Hydraulic disc
Fuel Tank Capacity	14.5 L (3.8 US gal)
Curb Weight	198 kg (437 lbs)
