7-32
NOTE: Do not squeeze/depress
the brake lever/pedal when the
pads are not in their positions. It is
difficult to push the pistons back
into position.
Rear Brake Adjustment
The rear brake pedal must be
adjusted to set the clearance
between the pedal and the foot-
rest. Adjust the brake pedal as fol-
lows:
45 – 55 mm
(1.8 – 2.2 in)
1. Loosen the lock nut 1, and
turn the push rod 2 to locate
the pedal 45 – 55 mm (1.8 –
2.2 in) below the top face of
the foot rest.
2. Retighten the lock nut 1 to
lock the push rod 2 in the
proper position.
 WARNING
If you ride this motorcycle after
brake system repair or brake
pad replacement without
pumping the brake lever/pedal,
you may get poor braking per-
formance which could result in
an accident.
After brake system repair or
brake pad replacement, pump
the brake lever/pedal several
times until brake pads are
pressed against the brake
disks and proper lever/pedal
stroke and firm feel are
restored.
 WARNING
Replacing only one of the two
brake pads can result in
uneven braking action and can
increase your chance of having
an accident.
Always replace both pads
together.

Suzuki SV650 Specifications

General

Bore x Stroke	81.0 mm x 62.6 mm
Compression Ratio	11.2:1
Fuel System	Fuel injection
Transmission	6-speed constant mesh
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Front Tire	120/70ZR17M/C (58W), tubeless
Rear Tire	160/60ZR17M/C (69W), tubeless
Overall Length	2, 140 mm (84.3 in)
Overall Width	760 mm (29.9 in)
Overall Height	1, 090 mm (42.9 in)
Wheelbase	1, 445 mm (56.9 in)
Ground Clearance	135 mm (5.3 in)
Seat Height	785 mm (30.9 in)
Ignition	Electronic ignition (transistorized)
Starter	Electric
Final Drive	Chain
Engine Type	645cc, 4-stroke, liquid-cooled, DOHC, 90° V-twin
Rear Brakes	Hydraulic disc
Fuel Tank Capacity	14.5 L (3.8 US gal)
Curb Weight	198 kg (437 lbs)
