7-33
INSPECTION AND MAINTENANCE
57RK0-14E
81A283
Headlight aiming
Since special procedures are required, ask
an authorized SUZUKI dealer for this job.
(21)
20 A
Power window timer
(22)
5 A
Key
(23)
15 A
Horn
(24)
5 A
Tail light (Left)
(25)
10 A
Tail light
(26)
10 A
Air bag
(27)
10 A
Ignition-1 signal
(28)
10 A
Back-up light
(29)
5 A
ACC-3
(30)
20 A
Rear defogger
(31)
10 A
Heated mirror
(32)
15 A
ACC-2
(33)
5 A
ACC
(34)
10 A
Rear wiper
(35)
5 A
Ignition-2 signal
(36)
15 A
Washer
(37)
25 A
Front wiper
(38)
10 A
Stop light
WARNING
Always replace a blown fuse with a
fuse of the correct amperage. Never
use a substitute such as aluminum
foil or wire to replace a blown fuse. If
you replace a fuse and the new one
blows in a short period of time, you
may have a major electrical problem.
Have your vehicle inspected immedi-
ately by an authorized SUZUKI dealer.
To Next Page
