Suzuki SX4 2016 User Manual

7-34
INSPECTION AND MAINTENANCE
83RM0-01E
(For K10C engine model)
83RM069
1) Lift the engine cover directly above.
68PM00734
2) Remove the bolts (1) and lift the air
cleaner case (2) directly above.
68PM00705
3) Unclamp the side clamps and remove
the element from the air cleaner case. If
it appears to be dirty, replace it with a
new one.
4) Clamp the side clamps securely.
5) Put the engine cover back into place.
(For K14C engine model)
83RM032
1) Lift the engine cover directly above.
(1)
(2)
(1)
