7-50
INSPECTION AND MAINTENANCE
83RM0-01E
*1: M16A engine models
*2: K10C and K14C engine models
*3: D16AA engine models
The main fuse, primary fuses and some of the
individual fuses are located in the engine
compartment. If the main fuse blows, no elec-
trical component will function. If a primary fuse
blows, no electrical component in the corre-
sponding load group will function. When
replacing the main fuse, a primary fuse or an
individual fuse, use a genuine SUZUKI
replacement.
To remove a fuse, use the fuse puller pro-
vided in the fuse box. The amperage of each
fuse is shown in the back of the fuse box
cover.
(9) 30 A Radiator fan 2
*2, *3
(10) 20 A Front fog light
(11) 7.5 A Headlight 2
(12) 25 A Headlight 3
(13) 25 A ESP
®
control module
(14) 25 A Headlight
(15) 30 A Back up
(16) 30 A DCDC 2 (AT IDL)
*2
(17) 40 A Ignition switch
(18) 40 A ESP
®
motor
(19) 30 A Starting motor
(20) 7.5 A Transaxle 3 (TCSS)
*3
(21) 30 A Fuel heater
*3
(22) 30 A Radiator fan
(23) 30 A Transaxle 2
(24) 40 A T/M pump
(25) 30 A DCDC
(26) 30 A FI main
*2, *3
(27) 20 A
FI
*1
Fuel pump
*2, *3
(28) 10 A Air compressor
(29) 15 A Transaxle 1 (GAS AT)
(30) 30 A Blower fan
(31) 15 A Transaxle 4 (TCSS)
*3
(32) 15 A
Transaxle 5
(AT IDL/TCSS)
(33) 7.5 A Starting signal
(34) 15 A Headlight (Left)
(35) 15 A Headlight high (Left)
(36)
10 A FI
*2
7.5 A FI 2
*3
(37) 20 A INJ DRV
*2, *3
(38) 15 A FI
*3
(39) 15 A Headlight (Right)
(40) 15 A Headlight high (Right)
(41) 50 A Ignition switch 2
*3
(42) 50 A Battery
*3
(43) 40 A Sub heater
*3
(44) 40 A Sub heater 3
*3
(45) 40 A Sub heater 2
*3
