7-44
Headlight
To replace the headlight bulb, per-
form the following steps:
1. Remove the right and left
bolts. Unhook the hooks.
Remove the headlight cover
1.
2. Remove the bolts. Unhook the
hooks. Remove the headlight
assembly 2.
3. Disconnect the socket 3 from
the headlight and remove the
rubber cap 4.
4. Unhook the bulb holder spring
5, and pull out the bulb 6.
5. To replace the headlight bulb,
reverse the above sequence.
NOTICE
The headlight bulb’s life may
be shortened by oil from your
fingers if you touch it.
When replacing the headlight
bulb, be careful not to touch
the glass. Grasp the new bulb
with a clean cloth.
