Suzuki VL800 User Manual

3-15
Turn Signal light Switch “”
4
Moving the switch to the “”
position will flash the left turn sig-
nals. Moving the switch to the “”
position will flash the right turn
signals. The indicator light will
also flash intermittently. To cancel
turn signal operation, push the
switch in.
Horn Switch “” 5
Press the switch to sound the
horn.
Hazard Warning Switch “” 6
All four turn signal lights and indi-
cators will flash simultaneously
when the switch is turned on with
the ignition switch in the “ON” or
“P” position. Use the hazard
warning lights to warn other traffic
during emergency parking or
when your vehicle could other-
wise become a traffic hazard.
 WARNING
Failure to use the turn signals,
and failure to turn off the turn
signals can be hazardous.
Other drivers may misjudge
your course and this may
result in an accident.
Always use the turn signals
when you intend to change
lanes or make a turn. Be sure
to turn off the turn signals after
completing the turn or lane
change.

Suzuki VL800 Specifications

General

Engine Type	4-stroke, liquid-cooled, SOHC, 45-degree V-twin
Displacement	805 cc
Bore x Stroke	83.0 mm x 74.4 mm
Compression Ratio	9.4:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Disc brake
Rear Brakes	Drum brake
Wheelbase	1, 655 mm (65.2 in)
Ground Clearance	140 mm (5.5 in)
Seat Height	700 mm (27.6 in)
Front Tire	130/90-16M/C 67H
Rear Tire	170/80-15M/C 77H
Overall Height	1, 110 mm (43.7 in)
