Suzuki VL800 User Manual

5-7
5. Park the motorcycle on a firm,
flat surface where it will not fall
over.
6. Turn the ignition switch to the
“OFF” position.
7. Turn the handlebars all the
way to the left and lock the
steering for security.
8. Remove the keys.
NOTE: If an optional anti-theft
lock such as a U-shape lock,
brake disk lock or chain is used to
avoid theft, be sure to remove the
anti-theft lock before moving the
motorcycle.
 WARNING
Hard braking on wet, loose,
rough, or other slippery sur-
faces can cause wheel skid
and loss of control.
Brake lightly and with care on
slippery or irregular surfaces.
 WARNING
Following another vehicle too
closely can lead to collision. As
vehicle speeds increase, stop-
ping distance increases pro-
gressively.
Always maintain a safe stop-
ping distance between you and
the vehicle in front of you.
NOTICE
Holding the motorcycle
stopped with throttle and
clutch lever operation on
inclines can damage the motor-
cycle’s clutch.
Use the brakes when stopping
the motorcycle on inclines.
 CAUTION
A hot muffler can cause severe
burns. The muffler will be hot
enough to cause burns for
some time after stopping the
engine.
Park the motorcycle where
pedestrians or children are not
likely to touch the muffler.

Suzuki VL800 Specifications

General

Engine Type	4-stroke, liquid-cooled, SOHC, 45-degree V-twin
Displacement	805 cc
Bore x Stroke	83.0 mm x 74.4 mm
Compression Ratio	9.4:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Disc brake
Rear Brakes	Drum brake
Wheelbase	1, 655 mm (65.2 in)
Ground Clearance	140 mm (5.5 in)
Seat Height	700 mm (27.6 in)
Front Tire	130/90-16M/C 67H
Rear Tire	170/80-15M/C 77H
Overall Height	1, 110 mm (43.7 in)
