Suzuki VL800 User Manual

7-16
SPARK PLUG CLEANING
To maintain a hot, strong spark,
keep the plugs free from carbon.
Adjust the gap to 0.8 – 0.9 mm
(0.031 – 0.035 in), 0.6 – 0.7 mm
(0.024 – 0.028 in) (California) for
good ignition. Use a thickness
(feeler) gauge to check the gap.
Installation
0.6 – 0.7 mm
(0.024 – 0.028 in)
(California)
0.8 – 0.9 mm
(0.031 – 0.035 in)
NOTICE
Improper installation of the
spark plug can damage your
motorcycle. An overly-tight or
cross-threaded spark plug will
damage the aluminum threads
of the cylinder head.
Carefully turn the spark plug
by hand into the threads. If the
spark plug is new, tighten it
with a wrench about 1/2 turn
past finger tight. If you are
reusing the old spark plug,
tighten it with a wrench about
1/8 turn past finger tight.
NOTICE
Dirt can damage the moving
engine parts of your motorcy-
cle if it enters an open spark
plug hole.
Cover the spark plug hole
while the spark plug is out of
the hole.

Suzuki VL800 Specifications

General

Engine Type	4-stroke, liquid-cooled, SOHC, 45-degree V-twin
Displacement	805 cc
Bore x Stroke	83.0 mm x 74.4 mm
Compression Ratio	9.4:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Disc brake
Rear Brakes	Drum brake
Wheelbase	1, 655 mm (65.2 in)
Ground Clearance	140 mm (5.5 in)
Seat Height	700 mm (27.6 in)
Front Tire	130/90-16M/C 67H
Rear Tire	170/80-15M/C 77H
Overall Height	1, 110 mm (43.7 in)
