7-59

Brake light/Taillight

1. Loosen the two screws and re-

move the lens.

2. Push in on the bulb, turn it to the

left, and pull it out.

License Plate Light

1. Loosen the screws and remove the

lens.

CAUTION

Overtightening the screws may cause the

lens to crack.

Tighten the screws only until they are

snug.

VS1400GLP03A.bookPage59Friday,October29,20042:01PM

Questions and Answers:

Need help?

Do you have a question about the Suzuki VS1400 and is the answer not in the manual?

Suzuki VS1400 Specifications

General

Engine Type	4-stroke, V-twin
Displacement	1360 cc
Cooling System	Air-cooled
Bore x Stroke	94.0 mm x 98.0 mm
Compression Ratio	9.0:1
Ignition	Electronic ignition (transistorized)
Transmission	5-speed
Final Drive	Shaft drive
Front Suspension	Telescopic fork
Front Brakes	Single disc
Rear Brakes	Drum
Fuel Capacity	13.0 liters
Seat Height	700 mm
