Sym Fiddle II 50 SYM Series User Manual

SYM 6. CYLINDER HEAD/VALVE
6-1
MECHANISM DIAGRAM....................6-1
PRECAUTIONS IN OPERATION .......6-2
TROUBLE SHOOTING.......................6-3
CAMSHAFT REMOVAL .....................6-4
CYLINDER HEAD REMOVAL ............6-6
CYLINDER HEAD DISASSEMBLY ....6-7
CYLINDER HEAD INSPECTION..........6-8
VALVE SEAT INSPECTION AND SERVICE
6-10
CYLINDER HEAD REASSEMBLY .......6-12
CYLINDER HEAD INSTALLATION......6-13
CAMSHAFT INSTALLATION ...............6-13
VALVE CLEARANCE ADJUSTMENT..6-14
MECHANISM DIAGRAM
0.8~1.2 kgf-m
0.7~1.1 kgf-m
1.0~1.4 kgf-m
0.8~1.2 kgf-m
1.0~1.4 kgf-m
