Sym Joymax Z+ User Manual

25
Coolant Level Inspection / Filling
 Position the scooter on level ground and in an upright position. The coolant inspection window ○A can
be seen on the left side of the floor panel.
 The coolant level must be between the “FULL” ○a and “LOW” ○b
marks.
 Top up the coolant when the level is at the “LOW” mark.
 Remove the left floor panel mat ○B .
 Remove the maintenance cap ○C with a flathead screw driver ○D .
 Open the reserve tank cap to fill in coolant.
 Reverse the above 3 steps to restore.
This scooter is filled with high quality coolant that is designed for the cooling system in the factory. It
contains a 50% solution of ethylene glycol based antifreeze.
Coolant Change
Contact an authorized SYM dealer to have the coolant changed.
It is highly recommended to use “SYM Long Life Coolant” or equivalent products when filling or changing
coolant. “SYM Long Life Coolant” is premixed and contains a 50% solution of ethylene glycol based
antifreeze, and does not need to be diluted before topping up or changing. “SYM Long Life Coolant” is
also contains corrosion inhibitor to protect the cooling system.
 Radiator coolant capacity: 1.4 liters.
Please refer to the below list of antifreeze concentration.
Antifreeze concentration
Temperature
Remark
20%
-8
To ensure antifreeze
performance, the original
equipped coolant has
50% of antifreeze.
30%
-15
40%
-24
50%
-36
○A
○a
○b
○B
○C
○D
○E
