6. Parts Location
Joymax Z+125 (LW12W2-EU)
Joymax Z 250 (LW25W2-EU)
Joymax Z 300 (LW30W2-EU)
(1)
(7)
(6)
(4)
(9)
(3)
(2)
(8)
(1). Windscreen
(2). Front Fork
(3). Coolant Level Inspection Window
(4). Side Stand Switch
(5). Side Stand
(6). Fuel Lid
(7). Seat / Luggage Box
(8). Tail / Brake Light
(9). Rear Turn Indicator
(10). License Plate Light
(11). Rear Shock Absorber
(12). Muffler
(13). Main Stand
(14). Rear View Mirrors
(15). Position Lights
(11)
(14)
(10)
(15)
(20)
(25)
(29)
(30)
(16). Headlight
(17). Left Turn Indicator/Front
(18). Right Turn Indicator/Front
(19). Passenger Footrests
(20). Rear Brake Fluid Reservoir
(16)
(21). Rear Brake Lever
(22). Left Handlebar Switches
(23). Battery Compartment
(24). Combination Instrument
(25). Front Brake Fluid Reservoir
(5)
(13)
(26). Front Brake Lever
(27). Throttle Grip
(28). Right Handlebar Switches
(29). Ignition Switch
(30). Front Compartment
(21)
(24)
(18)
(22)
(23)
(28)
(27)
(26)
(12)
(19)
(17)
