8 | IV-50 EC
6 Nameplate and type key
6.1 Nameplate
The following nameplate is shown as an example of formatting. The shown image is for the IV-50 EC model specically.
5.5 Dimensions
A B C D øE F G
IV-50 EC 10.8 (276) 32.8 (834) 7.3 (185) 14.5 (370) .5 (14) 10.2 (259) 50.5 (1284)
Dimensions are in inches (mm)
Note:
Variation in the current draw of an Electronically
Commutated Motor can be expected, which is
dependent on the line impedance.
• Current variation can be caused by the
distance of the fan unit from the voltage source,
which has an impact on total line impedance.
• For example, a long distance from the
transformer/supply results in increased line
impedance, which reduces the motor current
draw. In other words, the closer the unit is to the
voltage source, the lower the impedance, and
the higher the current draw.
i
