TB7100 Installation Guide Installation 5
© Tait Electronics Limited March 2006
1 Installation
This section describes how to install the base station in a standard 19-inch
rack or cabinet. It also provides some general information on safety
precautions and site requirements. We recommend that you read the entire
section before beginning the installation.
1.1 Personal Safety
1.1.1 Lethal Voltages
The base station may be fitted with an internal AC power supply unit. If an
internal AC power supply unit is fitted, a standard ICE AC power connector
is fitted in the rear panel of the base station (refer to “AC Power
Connection” on page 18).
Warning!! The internal AC power supply unit contains
voltages that may be lethal. Refer to the ratings
label on the rear of the base station. The internal
AC power supply contains no user-serviceable
parts.
Important Before connecting to the AC power connector, refer to the
ratings label on the rear of the base station for its configured
mains voltage.
The base station must be installed so that the rear of the base station is
located in a service access area. The plug of the AC power supply cord is
intended as the disconnect device. Therefore, the socket-outlet must be
installed near the equipment and must be readily accessible.
Ensure that all power sources (AC and
DC) are disconnected
before opening the base station.
1.1.2 Explosive Environments
Warning!! Do not operate base station equipment near
electrical blasting caps or in an explosive
atmosphere. Operating the equipment in these
environments is a definite safety hazard.
