Tait TB8100 Technical Support

Tait Confidential Tait Electronics Ltd
Telephone:+64-3-357-9991 TN-1013-AN
support@taitworld.com
http://support.taitworld.com Date of Print: 12/03/07 Page 2 of 9
4 Connecting the TB8100 to the T805 Equipment.
4.1 DB25 SIF Connections using TBA40xx-0B00 & TBA40xx-0C00 Reciters.
RSU J414 on T805 TB8100 SIF
Function Pin Pin Function
RX Audio + 1 1 RX Line Out +
RX Audio - 2 2 RX Line Out -
CTCSS Output 3 5 TX Audio In
TX Key 4 10 TX Key
Ground 5 4 Ground
RX Gate 6 9 RX Gate
TX Audio + 7 6 TX Line In +
TX Audio - 8 7 TX Line In -
4.2 TaitNet SIF Connections using TBA40xx-0K00, TBA40xx-0L00 or
TBA40xx-0T00 Reciters
.
RSU J414 on T805 TB8100 SIF
Function Pin Pin Function
RX Audio + 1 1 RX Line Out +
RX Audio - 2 2 RX Line Out -
CTCSS Output 3 6 TX Audio In
TX Key 4 5 TX Key
Ground 5 15 Ground
RX Gate 6 4 RX Gate
TX Audio + 7 7 TX Line In +
TX Audio - 8 8 TX Line In -
