Malfunctions
Technical data
Malfunction Possible causes Troubleshooting Page
Machine without function
Machine is switched off
• Switch on the main switch
71
No power supply
• Insert the power supply plug into
the mains socket
Main cord defect • Replace the main cord
Motor does not turn • Contact your service partner
Cylindrical brush is not turning
Brush drive switched off • Turn brush drive switched on 71
Motor does not turn • Contact your service partner
Switch not pressed • Press switch 71
Cylindrical brush not installed cor-
rectly
• Check the cylindrical brush and in-
sert correctly if necessary
72
Poor suction performance
Suction hose blocked • Wash out the squeegees 71
Suction hose defect • Contact your service partner
Little or no water
Fresh water tank filter blocked • Clean the fresh water tank filter 77
Pump switched off • Press function switch 71
Nozzles blocked • Clean nozzles 77
Machine
Working width 38 cm
Dimensions (LxWxH) 109 x 47 x 94 cm
Machine weight (empty tanks) 52 kg
Rated voltage 230-240V~ 220V~ 120V~ AC
Frequency 50 60 60 Hz
Power supply cord length 15 m
Rated power, nominal 2000 2000 1300 W
Fresh water tank, nominal +/- 5% 30
Values according to IEC 60335-2-68
Sound pressure level LpA 73 dB(A)
Uncertainty KpA 0.8 dB(A)
Vibration <2.5 m/s2
Uncertainty K 0.25 m/s2
Splash water guard IPX4
Protection class I
