18
D705M
-
-
DIAGNOSTICS LED
DL1 (STOP) STOP button green LED signal
DL2 (PEDESTRIAN) PEDESTRIAN button red LED signal
DL3 (STEP BY STEP)
DL4 (OPEN) OPEN button red LED signal
DL5 (CLOSE)
DL6 (SENSITIVE EDGE) SENSITIVE EDGE green LED signal
DL7 (PHOTOCELL)
DL8 (CLOSE LIMIT SWITCH)
DL9 (OPEN LIMIT SWITCH)
DL10 (RADIO CONTROLS)
red LED signal
: phototest error
Disable phototest (dip-switch 6 OFF), check operation and connection of photocells;
5 : absence of encoder signal
Check wiring, check encoder through TEST-ENCODER (optional);
6 : presence of obstacle after 5 failed attempts to close
Make sure there are no obstacles across the path of the gate and that it slides smoothly;
by the automation.
In the event of 5 consecutive activations (during the same closing manoeuvre) of the encoder (ob-
be repeated after each activation of the encoder.
ENGLISH
